EGAT Guanyin Branch

Configuration of Plant 1

Since EGAP divided up by EGAT, EGAP inherited EGAT NADCAP, subsequently EGAP
will be the new name of the company to apply for NADCAP certification.

EGAP 1F Machine Layout

AREA DESCRIPTION	ID	MAJOR EQUIPMENT
Post Processing Line		1.- Chemical Mill 2.- Conversion Coating 3.- Sulfuric Acid Anodizing 4.- Boric Sulfuric Acid Anodizing
EBW Line		(1) EBW Machine (1) Shot Peening Machine (1) Milling and Turning Center
Machining Line		(6) 5-Axis multi-tasking (1) 5-Axis Milling (1) 5-Axis Milling (17) 3-Axis Milling (1) Multi-tasking Machining (5) Turning Machine
RCB Line (BOEING)		Assembly Pictures/ Tools
Assembly Line (Reserved)		(Reserved)
Automatic Machine Line		Riveting Machine
Back Shops		Autoclave Shop / Miscellaneous Back Shops

EGAP 2F Machine Layout

AREA DESCRIPTION	ID	MAJOR EQUIPMENT
EDM Line		Milling and Turning Center; Small Hole Drilling Machine; Wire EDM; EDM; 7 AXIS EDM; 5 AXIS EDM; Abrasive Flow Machine; Abrasive Flow Machine

Ground Floor Layout 01 | Machining Line

Ground Floor Layout 02 | Assembly Line
